What is does
This modules allows users to build geo-routes from combination of partner addresses (res.partner)
Value & Benefit
- Manage unlimited routes with much and details information for each and every route (e.g. distance, average speed, waypoints in routes, etc)
- Inheritance from the existing model res.partner for addressing to shorten learning curves
- Ready for any routing application development (map integration, logistics, transportation, etc)
Key Features
Route design & building by combining waypoints
Each waypoint is link to an address (res.partner model)
Route sections is automatically computed and created combining two addresses of two consecutive waypoints in the route
Users can set distance and max moving speed for each and every section
Estimated Moving time through a section is computed base on the distance and the max moving speed of the section
Built for other extensions:
- sales delivery routes preparation
- fleet operation tracking
- transportation pricing
- automatic distance calculation is possible maybe when integrated with base_geolocalize module
- etc
Editions Supported
- Community Edition
- Enterprise Edition
Installation
- Navigate to Apps
- Find with keyword 'to_geo_routes'
- Install it as usual then you are done
Concepts
- Route Section: is a section defined by two addresses where each Address (aka From and To) is an Odoo partner record. This design model to ensure short learning curve and easy to extend and fully integrated with existing features in Odoo
- Waypoint: also known as "Route Waypoint", is a model that presents an instance of an Address which creates a data link between a Route and an Address in Odoo
- Section Line: also known as "Route Section", is a model that presents an instance of a Section which creates a data link between a Route and an Route Section in Odoo
- Route: is a model to present a route that defined by Waypoints and Sections. Then Odoo will automatically find and link the related Sections and Addresses for the Route
Instructions
- Without other modules that extending this module, you are required to be an administrator in Odoo to access the module's menu: Settings > Geo-Routes. If you have other modules that developed on top of this, there should be other ways to access the features. For example, if you have the module "Fleet Operation & Planning" installed, you may access the features through "Fleet Operation > Routes & Waypoints" which does not required administrator access rights. In this document, it is assumed that you have administration access rights.
- Define a new Route:
- Navigate to "Settings > Geo-Routes > Routes" to see the routes list view
- Hit Create button to open the route form view, on which you can input:
- The name of the route. For example: Hanoi to Ha Long Bay via Hai Phong City
- In the Waypoint table, you can start adding waypoints for your route
